Features

Improve output efficiency by special structure

High performance bearings. which are common features of the Luxxion series.
Stable motor control performance by low cogging torque.
In KG series. while taking advantage of this feature.
Regardless of the volume increase of neodymium magnet.
The motor itself can achieve high output characteristics!
Torque at acceleration and rolling at neutral
It is compatible with conflicting direct operation feeling.
Moreover. since heat generation is small with a high efficiency system installed.
The setting range of the gear ratio has expanded.

Next-generation design considering beauty when mounted on a vehicle

Adopted upper and lower center dividing method for aluminum scraping body.
In addition to the combination with mirror finish.
Three-dimensional line and laser processing engraved.
We are producing high-quality powerfulness.

Excellent rotor heat resistance

Permanent magnets are greatly affected by temperature.
When the temperature exceeds a certain temperature. the magnetic force is lost.
Even if it is returned to normal temperature it will not recover.
Like LUXON. in order to prevent loss of magnetic force due to temperature rise.
A sintered rotor using a neodymium magnet with higher heat resistance is adopted.

Black 12G cable with high color matching is adopted

Specifications · Specs

6.5 T

Input voltage (V) 4.8 to 11.1
KV (rpm / V) 5.790
Power (W) 380
Efficiency (%) 92
Rotor type Sintered �� 12.3 mm (neodymium magnet)
Coil winding method Star winding
